How deep should you set your trolling motor?
Choosing the correct trolling motor shaft length is important so that the angler’s electric motor does not cavitate, creating fish-spooking noise. The rule of thumb is that the top of the motor section should be submerged 12″.
Can you adjust depth of trolling motor?
Move the motor so that it stops halfway between the stowed and deployed positions. Loosen the collar at the base of the steering system housing. Raise or lower the depth of the trolling motor. …
Can a trolling motor shaft be too long?
A trolling motor shaft can be too long. If the trolling motor shaft is too long, you risk the propeller hitting bottom or the inability to stow the motor properly. Too long of a shaft can not only damage the propeller but also the rest of the motor and the environment beneath the water as well.
How big of a boat can a trolling motor push?
Trolling Motor Thrust Guide
| Boat Weight (lbs) | 1,500 | 2,500 |
|---|---|---|
| Boat Length | 14-16′ | 18′ |
| Minimum Thrust | 55 | 70 |
| Performance Thrust* | 55 | 80 |
| Motor Voltage | 12v | 24v |
How far below a boat should the prop be?
If you have a short shaft motor, the top most part of the transom and the lower most part of the boat should be about 15 to 16 inches. For a long shaft, I think 20 to 21 inches is correct.
How do you know if your outboard is too high?
Too high usually results in low water pressure, prop letting go in turns, or lack of bow lift are usually the telltale signs. Sometimes porpoising is caused by too much bow lift and dropping the motor will give it more bite and make it worse.
How deep should my prop be in the water?
What happens if outboard motor is too low?
If the outboard is too low, it creates excessive drag, which cuts into speed and fuel efficiency. If it’s too high, the propeller tends to ventilate, losing its bite on the water and blowing out while turning and in steep seas.
Can you shorten Minn Kota shaft?
Minn Kota trolling motors are often a bit more expensive than those made by other brands, so you may be a little more reluctant to cut and weld your Minn Kota. While it is possible to shorten a Minn Kota shaft on some models, it is best to let a professional do the work.
How does Minn Kota measure shaft length?
Measure down from the mounting surface of the transom or bow to the water level. Add 5″ to waterline measurement for fishing in rough water. Add 12″ to waterline measurement for steering a hand control motor while standing. Use this measurement and the tables below to find the appropriate shaft length.
How long will a 24v trolling motor last?
However, a 24-volt trolling motor should last at least 8-10 hours and may last up to several days before you need new or recharged batteries.
