How do I create a border in DraftSight?

Click a point in the drawing area, or press ENTER to insert the border at the 0,0,0 point. In the Edit Attributes dialog box, edit or add entries. Click OK….In the Drawing Borders with Title Block dialog box:

  1. Click Import.
  2. Select the *.
  3. Select the Perform rescale check box.
  4. Select the Move objects check box.
  5. Click OK.

How do I create a template in DraftSight?

Creating and Managing Sheets

  1. Click File > Sheet > Sheet from Template (or type Sheet and specify the Template option).
  2. In the Select template from file dialog box, select a *.
  3. In the Sheet List dialog box, select a Sheet name and click OK.
  4. The Sheet and all entities from the specified file are inserted in the drawing.

How do you insert a title block in DraftSight?

To add a Frame and a Title Block to a drawing: Do one of the following: On the ribbon, click Toolbox > Frame > Insert….Specify the Frame area.

  1. Click Specify area.
  2. In the graphics area, specify two diagonal points defining the rectangular are for the Frame with the Title Block.
  3. Click OK.

What is Title box and their uses?

d. Title box – An important feature which is a must in every drawing sheet. The title box is drawn at the bottom right hand corner of every drawing sheet and provides technical and administrative details regarding the drawing/component.

How do I add a sheet in DraftSight?

To create a new Sheet: Click File > Sheet > New Sheet (or type Sheet and specify the New option).

How do you use viewports in DraftSight?

To set the view direction by specifying a viewpoint:

  1. Do one of the following: Click View > 3D Views > Viewpoint on the menu.
  2. Type the new viewpoint, for example, 1,1,1. The viewpoint creates a vector to the origin of the coordinate system (0,0,0), which defines the direction from which the drawing is viewed.

How do you edit a title block in Draftsight?

To edit the values in the Title Block:

  1. Do one of the following: On the ribbon, click Toolbox > Frame > Edit. On the menu, click Toolbox > Frame > Edit. Type TB_EditFrame.
  2. In the graphics area, specify the Title Block.
  3. In the Edit BlockAttribute Values dialog box, modify the values.
  4. Click OK.

What are the hidden lines used for?

Hidden lines in a drawing represent the edges where surfaces meet but are not directly visible. Hidden lines are omitted from pictorial drawings unless they are needed to make the drawing clear. Figure 3.46 shows a case in which hidden lines are needed because a projecting part cannot be clearly shown without them.

What is layout of drawing sheet?

Layout of drawing sheets The drawing sheet consist of drawing space, title block and sufficient margins. After fixing the drawing sheet on the drawing board, margins should be drawn. The layout should facilitate quick reading of important particulars.
