How do you convert AWG to MM2?

This means for AWG = 1: The metric wire outside diameter is 0.127 * 92(32-1)/39 = 7.348 mm. The metric wire cross-section is 0.012668 mm2 * 92(36-1)/19.5 = 42.409 mm2.

What size is AWG in MM2?

A Simple Guide on Cable AWG to Metric Conversions

Metric MM2 (Diameter)	AWG	Approx Strading
0.75mm	20 awg	24/0.2
1mm	18 awg	32/0.2
1.5mm	16 awg	30/0.25
2.5mm	14 awg	50/0.25

What is 10 AWG wire in MM?

2.588mm
Wire Gauge Conversion

Wire Number (Gauge)	A.W.G. or B&S (Inches)	A.W.G. Metric (MM)
8	0.1285″	3.264mm
9	0.1144″	2.906mm
10	0.1019″	2.588mm
11	0.0907″	2.304mm

What AWG is 2mm?

American Wire Gauge to Metric Conversion Table

AWG	METRIC (mm2)	Our nearest Cable Approx.
14	2.08	2mm2
13	2.62	3mm 2
12	3.31	3mm2 or 4mm2
11	4.17	4.5 mm2

How many MM is a 16 gauge?

Sheet Steel Gauge Conversion Chart

Gauge No	Inch	Metric
13	0.092″	2.3mm
14	0.080″	2.0mm
15	0.072″	1.8mm
16	0.064″	1.6mm

What is the area in mm2 of a 000 AWG wire?

American Wire Gauge (AWG) vs. cross sectional area converter.

American Wire Gauge (#AWG)	Diameter (inches)	Cross Sectional Area (mm2)
0000 (4/0)	0.460	107
000 (3/0)	0.410	85.0
00 (2/0)	0.365	67.4
0 (1/0)	0.325	53.5

What AWG 1.5 mm2?

Wire Conversion-American Wire Gauge (AWG) to Square Millimeters (MM2)

Wire Size Conversion Chart – American Wire Gauge to square millimeters
AWG	mm2
18	0.75
17	1.0
16	1.5

What gauge is 6.7 mm wire?

Wire Gauge Chart

Wire Gauge	Washburn & Moen Steel Wire Gauge
1	.283″	7.2 mm
2	.263″	6.7 mm
3	.244″	6.2 mm
4	.225″	5.7 mm

How many mm is 12 gauge?

Sheet Steel Gauge Conversion Chart

Gauge No	Inch	Metric
11	0.116″	2.9mm
12	0.104″	2.6mm
13	0.092″	2.3mm
14	0.080″	2.0mm
