How do you decode Ford heads?

How do you decode Ford heads?

Look at the first letter. It denotes the decade when the head was produced, ranging alphabetically from A to G and beyond. The letter A denotes the decade of 1940. The B mark indicates 1950 and a C mark indicates the decade of 1960.

Where is the casting number on Ford heads?

The casting number is located under the valve cover, in the middle of the cylinder head. It is a combination of a number and four letters; C6ZZ-A, for example. According to ClassicMustang, casting numbers may change from year to year and are usually the same or nearly the same as the cylinder head part number.

How do I identify my FE heads?

FE cylinder heads are identifiable by their casting number and date code. This is a C0AE-6090-D cylinder head for 1960 352 and 1961–1962 390. The casting number (bottom arrows) is almost never the same as the Ford part number.

Where are casting numbers on 351W heads?

The 351W casting number is located on the right side of the block, about halfway down, facing downwards. The code will be a combination of letters and numbers — for example, “E3AE.” In this code, the E represents the decade number and the 3 represents the year. This engine was manufactured in 1983.

How do I know if my engine is a 289?

You need to look for the cast numbers on the engine. Those numbers are located near the place where the startmotor is . That photo could be a 289 or a 302, and there would be no way to tell.

How do I identify a Ford 260 head?

The 260 heads have larger 52- to 55-cc kidney-shaped chambers with the same valve size. Expect to see C2OE-F, C3OE-B prior to February of 1964. In February of 1964, Ford came out with an improved 260 head with larger 1.67/1.45- inch valves along with the same 52- to 55-cc chambers. The revised head is numbered C4OE-B.

How do I identify a 289 engine?

Registered. If you remove the Valve Covers the Heads will be Stamped 289 or 302 inside as well as a Date Code in this format: [7L22] or [8A2] for example. The Casting Numbers for the Cylinder Heads are on bottom and only visible if the Heads are removed, typically.

Are all 302 heads interchangeable?

Like the 289 heads mentioned earlier, all 302 heads are the same except for Thermactor provisions. There’s also a truck head (C9TE-C), which employs a 58.2-cc chamber for slightly higher compression. Ultimately all 302 heads were carryovers of the 289 head, making them all interchangeable.

How do I know if my Ford 427 is a side oiler?

Here’s the easiest way to tell if it’s a side oiler… The arrow is pointing at a pipe plug…. Of course it will have the hump on the side of the block, along with the pipe fittings on the side.

What did a 351 Windsor come in?

351W Vehicle Chart
